ESCApe32 ESC Wifi-Link Connector，Easily use wifi link to connect ESC and configure parameters

ESCape32 Wi-Fi Link is an ESP32-based embedded configurator for the ESCape32 firmware that works over Wi-Fi. It acts as a Wi-Fi access point named ESCape32-WiFi-Link that an external device connects to. A configuration window pops up automatically, but in case it doesn’t or is limited in functionality, simply navigate to escape32.local or 192.168.4.1 in the web browser once Wi-Fi connection has been established. The main highlights are:

• Real time configuration and firmware updates.
• RTTTL music is transparently converted to the native format.
• Any device with Wi-Fi and a web browser can be used (only one device can be connected at one time).

1. Download the latest pre-built combined image here.
2. Flash the image at offset 0x0 using the ESP Flash Tool or any DFU utility, e.g. dfu-util.

ESP Flash Tool step-by-step instructions:

1. Select ChipType.
2. Select LoadMode (USB).
3. Select and check the downloaded image.
4. Set offset to 0.
5. Select the corresponding COM port.
6. Click Start.

4-IN-1 ESC wifi link
